12V DC Brushless Fan Plastic Frame / Impeller Silent Cooling Type With Jack

Name: 12V DC Brushless Fan Plastic Frame Impeller Silent Cooling Type With Jack
Brand: MX/ODM/OEM
Price: 3.5 USD

Buy cheap 12V DC Brushless Fan Plastic Frame / Impeller Silent Cooling Type With Jack product

Brand Name : MX/ODM/OEM

Model Number : MX8025AB(S)U1

Certification : CE/ROHS

Place of Origin : China

MOQ : 500pcs

Price : USD3.5-5

Payment Terms : T/T

Supply Ability : 600,000pcs per month

Delivery Time : 15 working days after received your payment

Packaging Details : carton

Product Name : DC Brushless Fans

Voltage : 12V

Frame : Plastic

Impeller : Plastic

Bearing type : Ball Bearing/Sleeve bearing

Motor : Impedance Protected

Speed : 4000RPM

Air Flow : 34CFM

Noise Level : 25dB-A

Size : 80*80*25mm(3.2*3.2*1.0 Inch)

Contact Now

12V DC Brushless Fans / 80*80*25mm Cooling Fans , Silent Cooling Fans with Jack

12V DC Brushless Cooling Fan 80*80*25mm, silent and long lifetime , are widely used in computer assy, as well as home appliances , industrial production equipment , server system etc.

Description:

12V DC FAN,used for cooling and ventilation.
Frame:Plastic
Impeller:Plastic With 7 Blades
Stator& Rotor:Silicon steel
Magnet Wires:Copper 1 PEW
Bobbin:PA-66 UL 94 V-0
Bearing Type:Ball Bearing

Specification

Model	MX8025ABL1
Outline Dimension	808025mm
Rated Voltage	DC 12V
Voltage Range	DC 7V~13.8V
Rated Current	0.12A±10%
Power Consumption	1.56W±10%
Speed	4000RPM±10%
Max. Air flow	34CFM±10%
Max. Static Pressure	0.50/0.40Inch-H2O
Noise Level	26dB(A)
Weight	58g
Dielectric Strength	1800V/0.5mA/3s
Temperature Test of Run	t=<70K
Locked Rotor Protection	t=<130K
Environmental Specification	Operating Temperature:-10℃~70℃ Operating Humidity:20%~85%RH

12V DC Brushless Fan Plastic Frame / Impeller Silent Cooling Type With Jack

Package&Shipping:

Package: Carton or as customers'requirement.
Shipping: 1. Be delivered by express (UPS, FedEx, DHL, TNT).
2. Be shipped by vessel or by air or as customers’requirement.

12V DC Brushless Fan Plastic Frame / Impeller Silent Cooling Type With Jack

Certifications:

12V DC Brushless Fan Plastic Frame / Impeller Silent Cooling Type With Jack

Contact us:

If you have any question pls contact us
QQ: 3146648329
Wechat: Mollyshioops
Tel/Whatsapp: +8615270344076
